4.3 Key functions
Function of the keys
Cursor The location of the cursor on the display is indicated by flashing characters. This
could be a single digit when entering number; numeric sign ( + or -) ; measure-ment
units (g,kg,t etc.); or any other text field. Throughout this manual the location of the
cursor, in programming examples, will be indicated by parentheses ( ) around the
flashing characters.
↑
Select or Up Key. This key changes the field/digit under the cursor.
- Digit: Increase value by 1 for each key press. (0 follows 9).
- Dec. pt. Move decimal point. 0000(.)0000 changes to 00000(.)000
- Menu Increase menu number by 1. i.e. Fct. 1.(1).0 changes to
Fct. 1.(2).0
When the menu number reaches its maximum the next
↑
changes the
number to 1. i.e. Fct 1.(5).0 changes to Fct 1.(1).0
- Text Change text field. i.e. ”YES” to ”NO” or ”g” to ”kg” to ”t” etc.
- Sign Toggle ”+” to ”-”
→ Cursor or Right Key. This key moves the cursor onto the next field to be edited.
(usually the next on the right).
- Number Move cursor from 12(3).50 to 123(.)50 to 123.(5)0
- Text Move to next field. i.e. (kg)/min to kg/(min)
- Menu Move to next menu column: i.e. from Fct 1.(2).0 to Fct. 1.2.(1)
or
if the cursor is already in the rightmost column: invoke that menu
function. i.e. from Fct. 1.2.(1) press
→
to edit MASS FLOW format.
↵
Accept or Enter Key.
-Within a
function Accept changes (if any) and exit the function.
-Menu Move cursor to the next column on the left.
i.e. from Fct. 1.2.(1) back to Fct. 1.(2).0
If the cursor is already in the leftmost column then
↵
exits the menus.
See next box: ”To terminate” .
Note:
If numerical values are set that are outside the permissible input range, the display shows the
min. or max. . acceptable value. After pressing the
↵ the number may be corrected.
