TRITON SYSTEMS, INC.
SECTION 1 - INTRODUCTION OPERATION MANUAL - MODEL 9610
1-2
What’s in This Manual
This manual describes all operating features of the Model 9610
Single-Cassette Cash Dispenser.
The setup and operating procedures given in this manual are ap-
plicable to the Model 9610 Single-Cassette Cash Dispenser. If your
Cash Dispenser does not have the ability to perform some of the
features described in this manual, it is because your processor
does not support the feature or the dispenser was purchased with-
out that particular option.
In this manual, the terms Cash Dispenser, Dispenser, or Terminal
are used interchangeably.
Business Hours Service
The Model 9610 is certified for Business Hours Service. This means
that the currency should be removed from the dispenser and stored
in a safe location when the business is closed to the public.
Single-Cassette Cash Dispenser Features
The general features of the Model 9610 Single-Cassette Cash Dis-
penser are summarized in the following list:
• Uses an ordinary dial-up telephone line, instead of an expensive
leased line.
• 2400 bps (bits-per-second) modem standard (optional 14400
and 33600 bps modems available).
• Note tray holds approximately 750-1000 notes (average 800
notes). Actual capacity depends upon currency quality and
thickness.
• Storage compartment integrated into note tray holds rejected
notes for safekeeping and ease of accountability.
• Reliable friction-feed cash dispensing mechanism.
• High-capacity electronic journal can store up to 2045 of the
most recent transactions for later printout.
• Intuitive, user-friendly keypad and display interface.
• 320 x 240 dot resolution gray-scale (16 shades of gray) backlit
Liquid Crystal Display (LCD). Optional Color LCD display
available.
