Hired-Hand Mega-Cool rev 6-09 User Manual
Page 5
Part No. 4801-5120 Rev. 6-09
Mega-Cool System
Page 5
Sump Pump System Configuration Options
10’-80’ System Straight,
End-Mount, Sump Pump
10’-120’ System Straight, Center-
Mount, Sump Pump
Pads not
shown for
clarity
Ground
level
Pads not
shown for
clarity
Ground
level
The Mega-Cool system can be mounted in two sump pump configurations
depending on the application requirements. Know the application
requirements before starting the Mega-Cool installation.
Some of the pads have been removed from the figures for clarity.
Refer to the system specific figures for additional details.
Examples of sump pump application configurations:
