<9. Parameter Lists>
9-10
IM 01C25R03-01E
Relative
Index Index
Parameter Name Factory Default
Write
Mode
Explanation
24 2524 UNIT_SEL2 0 (Auto) O/S Selection of unit to be displayed. The unit of the parameter
which is selected at PARAMETER SEL2 will be displayed when
"Auto" is selected; user-specified unit at DISPLAY UNIT2 will be
displayed when "Custom" is selected.
25 2525 DISPLAY_UNIT2 Null O/S User specified unit to be displayed on display2, which will be
available when "Custom" is selected at UNIT SEL2.
26 2526 EXP_MODE2 0 O/S Selection of the displayed value in exponent such as x1, x10,
x100, and x1000.
27 2527 BLOCK_TAG3 2029
(SECONDARY_
VALUE)
— Block tag which includes a parameter to be displayed on
display3.
28 2528 PARAMETER_SEL3 1 (SECONDARY_
VALUE)
O/S Selection of a parameter to be displayed on display3.
Select a parameter from Table 6.1
29 2529 DISPLAY_TAG3 Null O/S Name of block tag to be displayed on display3; up to six
alphanumeric plus a slash [/] and a period [.]
30 2530 UNIT_SEL3 0 (Auto) O/S Selection of unit to be displayed. The unit of the parameter
which is selected at PARAMETER SEL3 will be displayed when
"Auto" is selected; user-specified unit at DISPLAY UNIT3 will be
displayed when "Custom" is selected.
31 2531 DISPLAY_UNIT3 Null O/S User specified unit to be displayed on display3, which will be
available when "Custom" is selected at UNIT SEL3.
32 2532 EXP_MODE3 0 O/S Selection of the displayed value in exponent such as x1, x10,
x100, and x1000.
33 2533 BLOCK_TAG4 2047 (CAP_
TEMP_VAL)
— Block tag which includes a parameter to be displayed on
display4.
34 2534 PARAMETER_SEL4 3 (CAP_TEMP_
VAL)
O/S Selection of a parameter to be displayed on display4.
Select a parameter from Table 6.1
35 2535 DISPLAY_TAG4 Null O/S Name of block tag to be displayed on display4; up to six
alphanumeric plus a slash [/] and a period [.]
36 2536 UNIT_SEL4 0 (Auto) O/S Selection of unit to be displayed. The unit of the parameter
which is selected at PARAMETER SEL4 will be displayed when
"Auto" is selected; user-specified unit at DISPLAY UNIT4 will be
displayed when "Custom" is selected.
37 2537 DISPLAY_UNIT4 Null O/S User specified unit to be displayed on display4, which will be
available when "Custom" is selected at UNIT SEL4.
38 2538 EXP_MODE4 0 O/S Selection of the displayed value in exponent such as x1, x10,
x100, and x1000.
39 2539 BAR_GRAPH_
SELECT
1 (display) O/S Selection of bar graph indicator.
40 2540 DISPLAY_CYCLE 3 (2.4s) O/S Duration of display cycle. (Time unit: 1=800ms)
41 2541 TEST40 0 — Not used for EJX.
42 2542 BLOCK_TAG5 Null — Block tag which includes a parameter to be displayed on
display5.
43 2543 PARAMETER_SEL5 4008 O/S Selection of a parameter to be displayed on display5.
Select a parameter from Table 6.1
44 2544 DISPLAY_TAG5 Null O/S Name of block tag to be displayed on display5; up to six
alphanumeric plus a slash [/] and a period [.]
45 2545 UNIT_SEL5 0 (Auto) O/S Selection of unit to be displayed. The unit of the parameter
which is selected at PARAMETER SEL5 will be displayed when
"Auto" is selected; user-specified unit at DISPLAY UNIT5 will be
displayed when "Custom" is selected.
46 2546 DISPLAY_UNIT5 Null O/S User specified unit to be displayed on display5, which will be
available when "Custom" is selected at UNIT SEL5.
47 2547 EXP_MODE5 0 O/S Selection of the displayed value in exponent such as x1, x10,
x100, and x1000.
48 2548 BLOCK_TAG6 Null — Block tag which includes a parameter to be displayed on
display6.
49 2549 PARAMETER_SEL6 4108 O/S Selection of a parameter to be displayed on display6.
Select a parameter from Table 6.1
50 2550 DISPLAY_TAG6 Null O/S Name of block tag to be displayed on display6; up to six
alphanumeric plus a slash [/] and a period [.]
51 2551 UNIT_SEL6 0 (Auto) O/S Selection of unit to be displayed. The unit of the parameter
which is selected at PARAMETER SEL6 will be displayed when
"Auto" is selected; user-specified unit at DISPLAY UNIT6 will be
displayed when "Custom" is selected.
