A8-15
IM 01C25R03-01E
Relative
Index Index
Parameter Name
Factory
Default
Write
Mode
Explanation
90 2090 REF_LIM_FDPMIN 7.0E-10 AUTO Lower limit to judge whether REFERENCE_FDP is available for
ILBD operation. Writable only when Diag Mode is Stop(0).
91 2091 REF_LIM_FSPMIN 1.0E-10 AUTO Lower limit to judge whether REFERENCE_FSPL and
REFERENCE_FSPH are available for ILBD operation.
Writable only when Diag Mode is Stop(0).
92 2092 REF_LIM_BLKFMAX 0.5 AUTO Upper limit to judge whether REFERENCE_BLKF is available for
ILBD operation.
Writable only when Diag Mode is Stop(0).
93 2093 COMP_FLG 0
(Compensation)
AUTO Whether RATIO_FDP is referred by CRATIO_FDP or NRATIO_FDP
is selected.
• Compensation(0)
• Non-Compensation(1)
94 2094 DIAG_LIM Refer to
Table A8.2
AUTO Set the ten threshold values for ILBD.
[1] Upper limit to detect “A Blocking”
[2] Lower limit to detect “B Blocking”
[3] Upper limit to detect “Large Fluctuation of Low Side”
[4] Lower limit to detect “Low Side Blocking”
[5] Upper limit to detect “Large Fluctuation of High Side”
[6] Lower limit to detect “High Side Blocking”
[7] Upper limit to detect “High Side Blocking” by using VALUE_BLKF
[8] Lower limit to detect “Low Side Blocking” by using VALUE_BLKF
[9] Upper limit to detect “Outside Diagnosis Range”
[10] Lower limit to detect “Outside Diagnosis Range”
Writable only when DIAG_MODE is Stop(0).
95 2095 DIAG_COUNT 3 AUTO When the statistical value such as VALUE_FDP and VALUE_BLKF
exceeds consecutively the threshold by number of times preset to
this parameter, it is estimated that the impulse line is plugged.
Writable only when DIAG_MODE is Stop(0).
If the process fluctuation values are unsteady, increase this
numbers to enhance the accuracy of the blockage detection.
96 2096 REFERENCE_TIME 0x00000000 AUTO The date and time when the reference values were obtained are
automatically recorded when DIAG_MODE is set to Reference (2).
97 2097 REFERENCE_FDP 0x00, 0 AUTO The reference value of VALUE_FDP obtained at normal operating
condition is automatically recorded when DIAG_MODE is set to
Reference (2).
98 2098 REFERENCE_FSPL 0x00, 0 AUTO The reference value of VALUE_FSPL obtained at normal operating
condition is automatically recorded when DIAG_MODE is set to
Reference (2).
99 2099 REFERENCE_FSPH 0x00, 0 AUTO The reference value of VALUE_FSPH obtained at normal operating
condition is automatically recorded when DIAG_MODE is set to
Reference (2).
100 2100 REFERENCE_BLKF 0x00, 0 AUTO VALUE_BLKF obtained under normal condition.
101 2101 REFERENCE_
DPAVG
0x00, 0 AUTO The average value of differential pressure obtained at normal
operating condition is automatically recorded when DIAG_MODE is
set to Reference (2).
102 2102 VALUE_TIME — The date and time when the statistical values such as VALUE_FDP
and VALUE_BLKF were calculated are recorded.
103 2103 VALUE_FDP — Average value of the sum of squares of differential pressure/
pressure fluctuations.
104 2104 VALUE_FSPL — Average value of the sum of squares of low-pressure side static
pressure fluctuations.
105 2105 VALUE_FSPH — The average value of the sum of squares of low-pressure side static
pressure fluctuations.
106 2106 VALUE_BLKF — Blockage degree characterized in comparison of high-pressure side
and low-pressure side pressure fluctuation values.
107 2107 VALUE_DPAVG — Ratio of the average of differential pressure/pressure to the
maximum span of an EJX
108 2108 RATIO_FDP — CRATIO_FDP or NRATIO_FDP is used by COMP_FLG setting.
VALUE_FDP decreases and this parameter is used to determine
whether single or both side is plugged.
