Ordering Information
(2201)
Series 96 9 6 — — – — — — — – — — — —
Microprocessor-based
1 / 16 DIN with universal input 1.
Options include software, power
supply, input 2, four outputs and
display color
Power Supply
A
= 100-240V ı (ac/dc)
B = 24-28V ı (ac/dc)
Input 2
0
= None
1 = Event input & 0-5V Î (dc)/
4-20mA (remote set point
input)
Output 1
C
= Switched dc/open collector
D = Electromechanical relay, Form C,
2A, without RC suppression
F = Universal Process, range
selectable: 0-20mA, 4-20mA,
0-5V
Î (dc), 1-5V Î (dc),
0-10V Î (dc)
K = 0.5A solid-state relay without
RC suppression
Output 2
A
= None
C = Switched dc/open collector
D = Electromechanical relay, Form C,
2A, without RC suppression
F = Universal Process, range selectable:
0-20mA, 4-20mA, 0-5V Î (dc),
1-5V Î (dc), 0-10V Î (dc)
K = 0.5A solid-state relay without
RC suppression
Output 3
A
= None
D = Electromechanical relay, Form C,
2A, without RC suppression
Output 4
A
= None
D = Electromechanical relay, Form C,
2A, without RC suppression
R = 232 Communications
U = 485 Communications
M = Universal Retransmit, range selectable: 0-20mA,
4-20mA, 0-5V Î (dc), 1-5V Î (dc),
0-10V Î (dc)
Software/Preset Parameters
00
= Standard software
AA = Ramping
XX = Custom software
XX = Preset parameters
Standard Display/Overlay
Upper Lower
Display Display
RR = Red Red
RG = Red Green
GR = Green Red
GG = Green Green
Ramping Display/Overlay
Upper Lower
Display Display
BA = Red Red
BB = Red Green
BC = Green Red
BD = Green Green
