NOTE: For more information about how parameter settings affect the controller’s operation, see Chapter Five, Features.
Active if output 2 is present, but
is not a process type (not 96 _
_-_ A _ _-_ _ _ __ or 96 _ _-_ F_
_-_ _ _ _), Output 2 (Output 2
Menu) is set to
[``AL] (Alarm)
and Setup Page Lock (Lockout
Menu) is not set to
[hide].
725 r/w [`yes] (1) [``no] no (0)
[`yes] yes (1) [Anu2] Alarm
Annunciation 2
Select alarm 2
annunciation option.
Active if output 2 is present, but
is not a process type (not 96 _
_-_ A _ _-_ _ _ __ or 96 _ _-_ F_
_-_ _ _ _), Output 2 (Output 2
Menu) is set to
[``AL] (Alarm)
and Setup Page Lock (Lockout
Menu) is not set to
[hide].
724 r/w [AL`0] (0) [Al`O] alarm condition
de-energizes output
(fail-safe operation)
(0)
[Al`C] alarm condition
energizes output (1)
[Lgc2] Alarm Logic 2
Select alarm 2 out-
put condition in the
alarm state.
Active if output 2 is present, but
is not a process type (not 96 _
_-_ A _ _-_ _ _ __ or 96 _ _-_ F_
_-_ _ _ _), Output 2 (Output 2
Menu) is set to
[``AL] (Alarm)
and Setup Page Lock (Lockout
Menu) is not set to
[hide].
723 r/w [both] (0) [both] both (0)
[``hi] high (1): high
side only
[``lo] low (2): low side
only
[Sid2] Alarm Active
Sides 2
Select which side or
sides the alarm set
points can be pro-
grammed for.
Active if output 2 is present, but
is not a process type (not 96 _
_-_ A _ _-_ _ _ __ or 96 _ _-_ F_
_-_ _ _ _), Output 2 (Output 2
Menu) is set to
[``AL] (Alarm)
and Setup Page Lock (Lockout
Menu) is not set to
[hide].
722 r/w [``no] (0) [``no] no action (0)
[`Yes] silence alarm
(1)
[SIL2] Silencing 2
Enable Silence 2.
Active if output 2 is present, but
is not a process type (not 96 _
_-_ A _ _-_ _ _ __ or 96 _ _-_ F_
_-_ _ _ _), Output 2 (Output 2
Menu) is set to
[``AL] (Alarm)
and Setup Page Lock (Lockout
Menu) is not set to
[hide].
721 r/w [``no] (0) [``no] no action (0)
[`Yes] latching en-
abled (1)
[LAT2] Latching 2
Enable Alarm 2
Latching.
Active if output 2 is present, but
is not process type (not 96 _ _-_
A _ _-_ _ _ __ or 96 _ _-_ F_ _-_
_ _ _), Output 2 (Output 2
Menu) is set to
[``AL] (Alarm)
and Setup Page Lock (Lockout
Menu) is not set to
[hide].
720 r/w 3°F, 2°C 1 to 9999 [ahy2] Alarm Hysteresis 2
Sets the switching
hysteresis for the
alarm output. This
defines a band on
the inside of the
alarm set point.
When the process
temperature is in
this band, the alarm
state will not
change.
6 . 1 2 ■ P a r a m e t e r s Wa t l o w S e r i e s 9 6
Setup Page / Output 2 Menu
Display Parameter Range Default Modbus Conditions for
(Modbus Value) Register Parameters to Appear
read/write
