Wa t l o w S e r i e s 9 6

W i r i n g

3 . 5

Output 2 Wiring

Figure 3.5a –

AC Outputs

•Electromechanical relay without contact suppression

96 _ _ - _ D _ _ _ - _ _ _ _

Form C, 2 amps,
off-state impedance:
31M

•Solid-state relay
without contact
suppression

96 _ _ - _ K _ _ - _ _ _ _

0.5 amps, off-state
impedance: 31M

Figure 3.5b –

Switched DC, Open Collector

96 _ _ - _ C _ _ - _ _ _ _

Open Collector

Max. voltage: 42VÎ (dc)

Max. current: 200mA

Switched DC

Max. dc supply current:
30mA

Supply voltage: 22 to 28VÎ (dc)

Figure 3.5c –

0-20mA and 4-20mA Process

96 _ _ - _ F _ _ - _ _ _ _

Maximum load
impedance: 800

Figure 3.5d –

0-5VÎ, 1-5VÎ and 0-10VÎ (dc) Process

96 _ _ - _ F _ _ - _ _ _ _

Minimum load
impedance: 1k

10

8

1

2

3

4

5

6

7

13 14 15

11

12

16 17 18

19 20 21

9

16 17

-

+

10

8

1

2

3

4

5

6

7

13 14 15

11

12

16 17 18

19 20 21

9

17 18

-

+

+V

Î

(dc)

Internal Circuitry

16

18

17

22 to 28V

Î

(dc)

10

8

1

2

3

4

5

6

7

13 14 15

11

12

16 17 18

19 20 21

9

+ 16 17 18 -

External
Load

COM.

10

8

1

2

3

4

5

6

7

13 14 15

11

12

16 17 18

19 20 21

9

External

Load

COM. N.C.

L2

L1

16 17 18

(18 used for

D outputs only)

N.O.

customer-supplied

Quencharc

NOTE:

Switching inductive loads
(relay coils, solenoids,
etc.) with the mechanical
relay, switched dc or
solid-state relay output
options requires use of
an R.C. suppressor.

Watlow carries the R.C.
suppressor Quencharc
brand name, which is a
trademark of ITW
Paktron. Watlow Part No.
0804-0147-0000.

ç

WARNING:

To avoid damage to
property and equipment,
and/or injury of loss of
life, use National Electric
Code (NEC) standard
wiring practices to install
and operate the Series
96. Failure to do so could
result in injury or death.
