Application 17
Automatic Deepfat Fryer

One Heat Channel, Four Menus

Introduction to Application 17 . . . . . . . . . . . . . 75
Configuration Mode Quick Reference . . . . . . . . 77
Program Mode Quick Reference . . . . . . . . . . . . 78
Step 7 Design a Faceplate Overlay . . . . . . . . . . 79
Step 8 Operate the Controller . . . . . . . . . . . . . 80

Application 17 allows you to program as many as four menu keys to control one temper-
ature channel and dual cooking time for an automatic deepfat fryer.

Overview of Key Steps

1.

Install the M

INI

C

HEF

2000.

2. Wire the controller.

3. Configure the controller.

4. Program the menus.

5. Set the controller security.

6. Set the Real-time Clock.

For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.

7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested

design to suit this application, see this section. For overlay dimensions and guide-
lines, see the Hardware & Software Setup Guide.)

8. Operate the controller. (See this application guide.)

17
