A p p l i c a t i o n 1 1

Wa t l o w M

I N I

C

H E F

2 0 0 0

1 1

Application 11
Automatic Deepfat Fryer
with Autolift Control

Single Heat Channel, 40 Menus

Introduction to Application 11 . . . . . . . . . . . . . 11
Configuration Mode Quick Reference . . . . . . . . 13
Program Mode Quick Reference . . . . . . . . . . . . 14
Step 7 Design a Faceplate Overlay . . . . . . . . . . 15
Step 8 Operate the Controller . . . . . . . . . . . . . 16

Application 11 is designed for the operation of a deep fat fryer. It includes one heat
channel, one cooking time, a mid-point alarm and autolift capability. The application
includes up to forty menus that control fryer temperatures and cooking time.

Overview of Key Steps

1.

Install the M

INI

C

HEF

2000.

2. Wire the controller.

3. Configure the controller.

4. Program the menus.

5. Set the controller security.

6. Set the Real-time Clock.

For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.

7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested

design to suit this application, see this section. For overlay dimensions and guide-
lines, see the Hardware & Software Setup Guide.)

8. Operate the controller. (See this application guide.)

11
