Application 13
Pressurized Automatic
Deepfat Fryer
Single Heat Channel, Six Menus
Introduction to Application 13 . . . . . . . . . . . . . 35
Configuration Mode Quick Reference . . . . . . . . 37
Program Mode Quick Reference . . . . . . . . . . . . 38
Step 7 Design a Faceplate Overlay . . . . . . . . . . 39
Step 8 Operate the Controller . . . . . . . . . . . . . 40
Application 13 allows you to program as many as six menus, each of which will control
one heat channel, one cooking time and a pressure release time.
Overview of Key Steps
1. Install the M INI C HEF 2000.
2. Wire the controller.
3. Configure the controller.
4. Program the menus.
5. Set the controller security.
6. Set the Real-time Clock.
For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.
7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested
design to suit this application, see this section. For overlay dimensions and guide-
lines, see the Hardware & Software Setup Guide.)
8. Operate the controller. (See this application guide.)
13
