2

Wa t l o w M

I N I

C

H E F

2 0 0 0

A p p l i c a t i o n 1 0

Key Functions in Configuration Mode

Key Functions in Operation Mode

ç

WARNING: The Basket Up and Basket Down Keys cause or initiate motion. Appropriate reasonable care should be
taken to prevent personal injury or machine damage as a result of operator initiated or unexpected machine motion.

Summary of Input/Output Functions

Note: For details, see wiring instructions in the

Hardware & Software Setup Guide.

Heat

Menu

1

Menu

2

Menu

4

Down

Your Company Logo

Up

Input 1 Fryer Temp

Input 2 not used

Event Input 1 not used

Event Input 2 not used

Output 1 Heat

Output 2 not used

Event Output 1 Lift Basket

Event Output 2 Drop Basket

Output 5 Audible Alarm

Menu

3

Heat

Menu

1

Menu

2

Menu

4

Down

Your Company Logo

Up

Menu

3

Heat indicator light Lit
when heat output is on.

Menu Keys Activate and
cancel menus, activate
cook cycle when
preheating, and
acknowledge alarms.

Increment and Basket Up
Lift basket.

Up and Down Indicator
Lights
Lit when up or
down outlets are
energized.

Decrement and Basket
Down
Lower basket.

A

B

D

E

G

H

Enter

Escape

Home

Edit

C

F

M

INI

C

HEF

2000

Display five-digit, seven-
segment numeric LED
display.

Indicator lights
(1 for each key, 2 for heat
channels).

Edit key (A) Access the
next level of parameters or
values.

Enter key (B) Enter the
value and return to
previous level.

Home key (D) Move to
Operation Mode with a
two-second key press.

Up key (C) Move up the
lists.

Escape key (E) Return to
original value when editing
a parameter value.

Down key (F) Move down
the lists.
