5.3.5 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
SATA Controller(s)
[Enabled]
SATA Mode Selection [IDE]
S_ATA1 Empty
S_ATA2 Empty
S_ATA3 Empty
S_ATA4 Empty
M-SATA1 Empty
Enable or disable SATA
Device.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
SATA Controller(s) [Enabled]
Use the SATA Controller(s) option to configure the SATA controller.
Enabled D EFAULT Enable SATA controller.
Disabled Disable SATA controller.
SATA Mode Selection [IDE]
Use the SATA Mode Selection option to configure SATA devices.
IDE D EFAULT Configures SATA devices as normal IDE device.
AHCI Configures SATA devices as AHCI device.
RAID Configures SATA devices as RAID device.
