NANO-QM871 EPIC SBC
Page 100
5.4.1 System Agent (SA) Configuration
Use the System Agent (SA) Configuration menu (BIOS Menu 20) to configure the
System Agent (SA) parameters.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
VT-d Capability Supported
VT-d [Disabled]
> Graphics Configuration
> NB PCIe Configuration
> Memory Configuration
Check to enable VT-d
function on MCH.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 20: System Agent (SA) Configuration
VT-d [Disabled]
Use the VT-d option to enable or disable VT-d support.
Disabled D EFAULT Disables VT-d support.
Enabled Enables VT-d support.
5.4.1.1 Graphics Configuration
Use the Graphics Configuration (BIOS Menu 21) menu to configure the video device
connected to the system.
