NANO-QM871 EPIC SBC
Page 103
1920x1080 48Bit
1920x1200 48Bit
2048x1536 48Bit
Backlight Control [Inverted]
Use the Backlight Control option to select the backlight control mode.
Normal The LVDS backlight is brighter at low voltage level.
Inverted D EFAULT The LVDS backlight is brighter at high voltage level.
5.4.1.2 NB PCIe Configuration
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PCIEX16
Not Present
PCIEX16 – Gen X [Auto]
Enable PEG [Auto]
Detect Non-Compliance Device [Disabled]
Configure PCIEx16
Gen1-Gen3
----------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 22: NB PCIe Configuration
PCIEX16 – Gen X [Auto]
Use the PCIEX16 – Gen X option to select the support type of the PCI Express x16 slot.
The following options are available:
Auto Default
Gen1
Gen2
Gen3
