NANO-QM871 EPIC SBC
Page 93
IO=3E8h;
IRQ=10
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10
IO=3E8h;
IRQ=10, 11
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10, 11
IO=2E8h;
IRQ=10, 11
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10, 11
IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11
IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
5.3.11 F81866 H/W Monitor
The F81866 H/W Monitor menu (BIOS Menu 15) displays the system temperature and
voltages.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
System temperature : +40 C
+VCC_CORE : +1.720 V
+V5S : +5.087 V
+V12S : +11.704 V
+V1.5 : +1.584 V
+V3.3S : +3.344 V
VSB3V : +3.344 V
VBAT : +3.056 V
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 15: F81866 H/W Monitor
