3.1.2 Peripheral Interface Connectors
The table below shows a list of the peripheral interface connectors on the NANO-QM871.
Detailed descriptions of these connectors can be found below.
Connector Type Label
Audio connector 10-pin header AUDIO1
Battery connector 2-pin wafer BAT1
Digital I/O connector 10-pin header DIO1
EC debug port 20-pin header LPT_DB1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 4-pin wafer SYS_FAN1
Power LED and HDD LED connector 6-pin wafer F_PANEL1
Keyboard and mouse connector 6-pin wafer KB_MS1
LAN active LED connector 4-pin header LAN_ACT_LED1
LVDS connector 30-pin crimp LVDS1
LVDS backlight connector 5-pin wafer INV1
PCIe Mini card slot PCIe Mini card slot M-SATA1
PCIe/104 slot PCIe/104 slot PCIE-104
Power button 2-pin wafer PWR_BTN1
Power connector (12V) 4-pin connector PWR1
Reset button 2-pin wafer RST_BTN1
RS-232 serial ports 10-pin header COM1, COM2
RS-422/485 serial port 4-pin wafer COM3
SATA 6Gb/s connectors SATA connector S_ATA1, S_ATA2
SATA power connectors 2-pin wafer
SATA_PWR1,
SATA_PWR2
SMBus connector 4-pin wafer SMB1
SO-DIMM connector SO-DIMM connector DIMM1
