5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Main
Advanced
Chipset
Boot
Security
Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version
4.6.5.4
Compliancy
UEFI 2.3.1; PI 1.2
Project Version
E416AR05.ROM
Build Date and Time
08/28/2013 14:08:15
iWDD Vendor
iEi
iWDD Version
B271ER15.bin
Processor Information
Name
Haswell
Brand String
Intel(R) Core(TM) i5-440
Frequency 2700
MHz
Processor ID
306c3
Stepping CO
Number of Processors
2Core(s) / 4Thread(s)
Microcode Revision
7
GT Info
GT3 (800 MHz)
IGFX VBIOS Version
2167
Memory RC Version
1.0.0.0
Total Memory
2048 MB (DDR3)
Memory Frequency
1333 MHz
PCH Information
Name
LynxPoint
PCH SKU
QM87
Stepping 04/C1
LAN PHY Revision
A3
ME FW Version
9.0.10.1372
ME Firmware SKU
5MB
SPI Clock Frequency
DOFR Support
Unsupported
Read Status Clock Frequnecy
50 MHz
Write Status Clock Frequnecy
50 MHz
Fast Read Status Clock Frequnecy 50 MHz
System Date
[Tue 10/15/2013]
System Time
[15:10:27]
Access Level
Administrator
Set the Date. Use Tab to
switch between Date
elements.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 1: Main
