NANO-QM871 EPIC SBC
Page 90
5.3.10 F81866 Super IO Configuration
Use the F81866 Super IO Configuration menu (BIOS Menu 13) to set or change the
configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
F81866 Super IO Configuration
F81866 Super IO Chip
F81866
> Serial Port 1 Configuration
> Serial Port 2 Configuration
> Serial Port 3 Configuration
Set Parameters of Serial
Port 1 (COMA)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 13: F81866 Super IO Configuration
5.3.10.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 14) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings
[Auto]
Enable or Disable Serial
Port (COM)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 14: Serial Port n Configuration Menu
