NANO-QM871 EPIC SBC
Page 17
Connector Type Label
SPI Flash connector 6-pin wafer SPI1
SPI Flash connector (EC) 6-pin wafer SPI2
TPM connector 20-pin header TPM1
USB 2.0 connector 8-pin header USB1
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the rear panel connectors on the NANO-QM871. Detailed
descriptions of these connectors can be found in a later section.
Connector Type Label
Ethernet connectors RJ-45 LAN1, LAN2
HDMI connectors HDMI HDMI1, HDMI2
USB 2.0 connector USB 2.0 USB_CON2
USB 3.0 connector USB 3.0 USB_CON1
VGA connector DB-15 VGA1
Table 3-2: Rear Panel Connectors
3.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the NANO-QM871.
3.2.1 Audio Connector
CN Label: AUDIO1
CN Type: 10-pin header
CN Location: See Figure 3-2
CN Pinouts: See Table 3-3
