Figure 4-13: lvds connector – IEI Integration NANO-QM871 User Manual
Page 78

NANO-QM871 EPIC SBC
Page 63
WARNING:
The diagram below is merely for illustration. The configuration and
connection of the cables from the TFT LCD screen being installed may
be different. Please refer to the installation manual that came with the
TFT LCD screen.
Figure 4-13: LVDS Connector
Step 3:
Locate the backlight inverter connector. The location of the backlight inverter
connector is shown in Chapter 3.
Step 4:
Connect backlight connector. Connect the backlight connector to the driver
TFT LCD PCB as shown in Figure 4-14. When inserting the cable connector,
make sure the pins are properly aligned.
