NANO-QM871 EPIC SBC
Page 30
Pin Description Description Pin
79 GND GND 80
81 SATA_T1p SATA_T0p 82
83 SATA_T1n SATA_T0n 84
85 GND GND 86
87 SSTX1p SSTX0p 88
89 SSTX1n SSTX0n 90
91 GND GND 92
93 Reserved Reserved 94
95 Reserved Reserved 96
97 GND GND 98
99 SATA_DET#1 SATA_DET#0 100
101 SATA_PWREN#1 SATA_PWREN#0 102
103 GND
+5 V
o
lts
GND 104
105 STK2 / SDVO_DAT LPC_CLK 106
107 GND GND 108
109 PEx4_1R(0)p PEx4_0R(0)p 110
111 PEx4_1R(0)n PEx4_0R(0)n 112
113 GND GND 114
115 PEx4_1R(1)p PEx4_0R(1)p 116
117 PEx4_1R(1)n PEx4_0R(1)n 118
119 GND GND 120
121 PEx4_1R(2)p PEx4_0R(2)p 122
123 PEx4_1R(2)n PEx4_0R(2)n 124
125 GND GND 126
127 PEx4_1R(3)p PEx4_0R(3)p 128
129 PEx4_1R(3)n PEx4_0R(3)n 130
131 GND GND 132
133 SATA_R1p SATA_R0p 134
135 SATA_R1n SATA_R0n 136
137 GND GND 138
139 SSRX1p
+12 V
o
lts
SSRX0p 140
