Enabled D EFAULT Legacy USB support enabled
Disabled Legacy USB support disabled
Auto Legacy USB support disabled if no USB devices are
connected
5.3.9 iWDD H/W Monitor
The iWDD H/W Monitor menu (BIOS Menu 11) displays the CPU temperature and CPU
fan speed, and contains the fan configuration submenu.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
CPU temperature : +60 C
CPU_FAN1 Speed : 5504 RPM
SYS_FAN1 Speed : N/A
> Smart Fan Mode Configuration
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 11: iWDD H/W Monitor
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
CPU Temperature
CPU Fan Speed
System Fan Speed
5.3.9.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 12) to configure the
smart fan temperature and speed settings.
