NANO-QM871 EPIC SBC
Page 7
1.6 Technical Specifications
The NANO-QM871 technical specifications are listed in Table 1-1.
Specification NANO-QM871
Form Factor EPIC
CPU 4
th
generation 22nm Intel® mobile Core™ i7/i5/i3 or Celeron® CPU
PCH Intel® QM87
Memory One 204-pin 1600/1333 MHz DDR3/DDR3L SO-DIMM supported
(system max. 8 GB)
Graphics Engine Gen 7.5 Intel® HD Graphics with DirectX 11.1, OpenGL 3.2 and
OpenCL 1.2 support
Display Output 1 x VGA (1920x1200@60)
1 x 18/24-bit dual-channel LVDS (2500x1600@60)
2 x HDMI with v1.4a compliant (2500x1600@60)
Supports triple independent display with dual HDMI+VGA/
dual HDMI+LVDS/HDMI+VGA+LVDS
Ethernet Controllers LAN1: Intel® I217 PHY with Intel® AMT 9.0 support
LAN2: Intel® I211AT PCIe Ethernet controller
Audio Realtek ALC662 HD Audio codec
One internal audio connector (10-pin header)
Super I/O Controller Fintek F81866
Embedded Controller iWDD
BIOS UEFI BIOS
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion 1 x Full-size PCIe Mini card slot with mSATA support
1 x PCIe/104 Type 2 slot
Digital I/O 8-bit, 4-bit input/4-bit output
Fan Connectors 1 x 4-pin wafer for CPU fan
1 x 4-pin wafer for system fan
