NANO-QM871 EPIC SBC
Page 95
NOTE:
The following five options appear when the Console Redirection
option is enabled.
Terminal Type [ANSI]
Use the Terminal Type option to specify the remote terminal type.
VT100 The target terminal type is VT100
VT100+ The target terminal type is VT100+
VT-UTF8 The target terminal type is VT-UTF8
ANSI D EFAULT The target terminal type is ANSI
Bits per second [115200]
Use the Bits per second option to specify the serial port transmission speed. The speed
must match the other side. Long or noisy lines may require lower speeds.
9600 Sets the serial port transmission speed at 9600.
19200 Sets the serial port transmission speed at 19200.
38400 Sets the serial port transmission speed at 38400.
57600 Sets the serial port transmission speed at 57600.
115200 D EFAULT Sets the serial port transmission speed at 115200.
Data Bits [8]
Use the Data Bits option to specify the number of data bits.
7 Sets the data bits at 7.
8 D EFAULT Sets the data bits at 8.
