NANO-945GSE2
Page 56
2
[email protected] or visit the IEI website (
2
http://www.ieiworld.com.tw )
to find out more about the available chassis.
4.6.2 Motherboard Installation
To install the NANO-945GSE2 motherboard into the chassis please refer to the reference
material that came with the chassis.
4.7 Internal Peripheral Device Connections
The cables listed in are shipped with the NANO-945GSE2.
Quantity Type
1 AT Power cable
1 Keyboard and Mouse cable
1 RS-232 cable
2 SATA drive cable
Table 4-8: IEI Provided Cables
Some optional items that can be purchased separately and installed on the
NANO-945GSE2 include:
ATX power cable
Dual port USB cable
Parallel port cable
RS-232 cable
RS-422/485 cable
SATA 5V power output cable kit for NANO series
SATA power cable
4.7.1 AT Power Connection
Follow the instructions below to connect the NANO-945GSE2 to an AT power supply.
