NANO-945GSE2
Page 89
o CPU Core
o +1.05V
o +3.30V
o +12.0 V
o +1.5V
o +1.8V
o 5VSB
o VBAT
5.3.5 Power Configuration
Use the Power Configuration Menu to set select AT or ATX power modes. This menu
also displays the current AT/ATX jumper setting.
BIOS Menu 8: Power Configuration
When ATX power is selected the following menu appears (
880H782H
BIOS Menu 9). The
Advanced Power Configuration menu (
880H783H
BIOS Menu 9) configures the Advanced
Configuration and Power Interface (ACPI) and Power Management (APM) options.
