NANO-945GSE2

Page 39

PIN DESCRIPTION

1 KB

DATA

2 MS

DATA

3 GND

4 VCC

5 KB

CLOCK

6 MS

CLOCK

Table 3-24: Keyboard Connector Pinouts

3.4.2 LAN Connectors

CN Label:

LAN1 and LAN2

CN Type:

RJ-45

CN Location:

See

7

Figure 3-23

CN Pinouts:

See

7

Table 3-25

The NANO-945GSE2 is equipped with two RJ-45 Ethernet controllers. The controllers

connect to the LAN through two RJ-45 LAN connectors. The pin assignments are listed

below.

PIN DESCRIPTION PIN

DESCRIPTION

1 MDIA3-

5 MDIA1+

2 MDIA3+

6 MDIA2+

3 MDIA2-

7 MDIA0-

4 MDIA1-

8 MDIA0+

Table 3-25: LAN Pinouts

Figure 3-25: RJ-45 Ethernet Connector
