NANO-945GSE2
Page 7
Specification/Model NANO-945GSE2
Keyboard/Mouse One PS/2 port
LPT One internal parallel port connector
Serial Ports Three RS-232 port (one external, two internal connectors)
One RS-232/422/485 (internal)
USB 2.0/1.1 ports Two external USB ports
Four via internal pin headers
Storage
CompactFlash® One CompactFlash® Type II socket
Serial ATA Two independent serial ATA (SATA) channels with 1.5 Gb/s
data transfer rates
Environmental and Power Specifications
Power Supply AT/ATX supported
Power Consumption 12V @ 1.45 A
(1.6 GHz Intel® Atom™ one 1.0 GB DDR2 SO-DIMM)
Temperature (operating) 0ºC ~ 60ºC (32ºF - 140ºF)
Humidity (operating) 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 115mm x 165mm
Weight GW/NW 700g/350g
Table 1-1: Technical Specifications
