3.2 Peripheral Interface Connectors
6
Table 3-1 shows a list of the peripheral interface connectors on the NANO-945GSE2.
Detailed descriptions of these connectors can be found below.
Connector Type Label
+12V power source connector (option) 2-pin? CN5
5V power connector 3-pin wafer J5
AT/ATX power input connector 4-pin (2x2) PW1
Audio connector 9-pin header J8
Backlight inverter connectors
5-pin wafer INV1
Battery connector
2-pin wafer BT1
CompactFlash® socket 50-pin CF socket J9
DD2 SO-DIMM slot SO-DIMM socket DIMM1
Digital input/output (DIO) connector 10-pin header DIO1
Fan connector 3-pin wafer J1
Front panel connector 8-pin header F_PANEL1
Infrared interface (IrDA) connector 5-pin header IR1
LVDS connector 30-pin crimp LVDS1
Parallel port connector 26-pin header J3
PC/104 104-pin ISA bus J6
PCI-104 slot 120-pin socket J4
Reset button 2-pin wafer RST1
Serial ATA (SATA) drive connector
7-pin SATA SATA1
Serial ATA (SATA) drive connector
7-pin SATA SATA2
Serial ATA (SATA) power connector
4-pin wafer CN1
Serial ATA (SATA) power connector 4-pin wafer CN2
Serial port connector (RS-232) 10-pin header COM2
Serial port connector (RS-232) 10-pin header COM4
