IMBA-C604EP ATX Server Board
Page 48
4.2.1 Socket LGA2011 CPU Installation
WARNING:
CPUs are expensive and sensitive components. When installing the
CPU, please be careful not to damage it in anyway. Make sure the
CPU is installed properly and ensure the correct cooling kit is properly
installed.
DO NOT touch the pins at the bottom of the CPU. When handling the
CPU, only hold it on the sides.
To install the CPU, follow the steps below.
Step 1: Disengage the load levers. Disengage the load levers in the order as shown in
Figure 4-1. To release the load lever, press the lever down and slightly outward
to clear the retention tab.
Figure 4-1: Disengage the CPU Socket Load Levers
Step 2: Open the load plate and remove the protective cover. Press the load lever
on the left hand side to lift the load lever, and then open it all the way. The black
