5.3.9.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 13) to configure fan
speed settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control
[Auto Duty-Cycle Mode]
CPU Temperature 1
60
CPU Temperature 2
50
CPU Temperature 3
40
CPU Temperature 4
30
CPU_FAN6 Smart Fan Control
[Auto Duty-Cycle Mode]
System Temperature 1
60
System Temperature 2
50
System Temperature 3
40
System Temperature 4
30
Smart Fan Mode Select
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: Smart Fan Mode Configuration
Î CPU_FAN1 Smart Fan Control/CPU_FAN6 Smart Fan Control [Auto Duty-Cycle
Mode]
Use the CPU_FAN1 Smart Fan Control/CPU_FAN6 Smart Fan Control option to
configure the CPU/System Smart Fan.
