IMBA-C604EP ATX Server Board
Page 84
Î
IO=2C0h;
IRQ=3, 4
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ3, 4
Î
IO=2C8h;
IRQ=3, 4
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ3, 4
5.3.9 F81866 H/W Monitor
The F81866 H/W Monitor menu (BIOS Menu 12) contains the fan configuration
submenus and displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU temperature :+43 C
System Temperature :+46 C
CPU_FAN1 Speed :2145 RPM
CPU_FAN6 Speed :N/A
+CPU_CORE :+0.896 V
+3.3V :+3.264 V
PVSA_CPU :+0.888 V
PVDDR_AB :+1.352 V
VSB5V :+4.896 V
+V3.3S :+3.264 V
VSB3V :+3.312 V
VBAT :+2.944 V
Smart Fan Mode Select
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: F81866 H/W Monitor
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o System Temperature
ƒ Fan Speeds:
o CPU Fan Speed
