IMBA-C604EP ATX Server Board
Page 22
NOTE:
Installing the memory modules with the same memory size is highly
recommended.
Figure 3-6: DDR3 DIMM Slot Locations
3.2.6 Digital I/O Connector
CN Label: DIO1
CN Type: 10-pin header
CN Location: See Figure 3-7
CN Pinouts: See Table 3-6
The digital I/O connector provides programmable input and output for external devices.
The digital I/O provides 4-bit output and 4-bit input.
