5.4.1.1 NB PCIe Configuration
Use the NB PCIe Configuration (BIOS Menu 20) menu to set the link speed for the PCI
Express slots.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PCIEX8_SLOT1 Speed [GEN2]
PCIEX8_SLOT2 Speed [GEN2]
PCIEX8_SLOT3 Speed [GEN2]
PCIEX8_SLOT4 Speed [GEN2]
Select Target Link Speed
Gen1, Gen2 or Gen3.
----------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: NB PCIe Configuration
Î PCIEX8_SLOT n Speed [GEN2]
Use the PCIEX8_SLOT n Speed option to select the target link speed of the PCI Express
slot. The following options are available:
ƒ GEN1
ƒ GEN2 Default
ƒ GEN3
