IEI Integration IMBA-C604EP - Manual (Page 114)

IMBA-C604EP ATX Server Board
Page 98
Î FRB-2 Timer [Enabled]
Use the FRB-2 Timer option to enable or disable the FRB-2 timer (POST timer).
Î
Enabled D EFAULT The FRB-2 timer is started during POST.
Î
Disabled Disables the FRB-2 timer.
NOTE:
The following two items will be available to configure when the FRB-2
Timer is enabled.
Î FRB-2 Timer timeout [6 minutes]
Use the FRB-2 Timer timeout option to set the FRB-2 timer expiration value. The
following values are available:
ƒ 3 minutes
ƒ 4 minutes
ƒ 5 minutes
ƒ 6 minutes Default
Î FRB-2 Timer Policy [Reset]
Use the FRB-2 Timer Policy option to configure how the system should respond if the
FRB-2 timer expires. The following options are available:
ƒ Do Nothing
ƒ Reset Default
ƒ Power Down
Î OS Watchdog Timer [Disabled]
Use the OS Watchdog Timer option to enable or disable the OS Boot Watchdog timer.
