IMBA-C604EP ATX Server Board
Page 91
5.3.12.1 NIC Configuration
Use the NIC Configuration submenu (BIOS Menu 17) to configure LAN port settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Link Speed
[AutoNeg]
Wake on LAN [Enabled]
Change link speed and
duplex for current port.
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 17: NIC Configuration
Î Link Speed [AutoNeg]
Use the Link Speed option to set the link speed and duplex mode of the LAN port.
Selecting AutoNeg allows the system to decide the transmission mode according to the
connected devices. Configuration options are listed below.
ƒ AutoNeg Default
ƒ 10 Mbps Half
ƒ 10 Mbps Full
ƒ 100 Mbps Half
ƒ 100 Mbps Full
Î Wake on LAN [Enabled]
Use this option to turn on or off the Wake-on-LAN function.
Î
Disabled Disables the Wake-on-LAN function
Î
Enabled D EFAULT Enables the Wake-on-LAN function
