IMBA-C604EP ATX Server Board
Page 17
Connector Type Label
SAS SMBus connector 4-pin wafer SAS_SMBUS1
SATA 3Gb/s drive connector 7-pin SATA connector
SATA3, SATA4,
SATA5, SATA6
SATA 6Gb/s drive connector 7-pin SATA connector SATA1, SATA2
SMBus connector 4-pin wafer SMBUS_1
SPI ROM connector 6-pin wafer JSPI1
TPM connector 20-pin header TPM1
USB 2.0 connectors 10-pin header
USB1, USB2,
USB3
USB 2.0 connector (Type A) 4-pin Type A USB4
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the connectors on the external I/O panel.
Connector Type Label
Audio connector Audio jack AUDIO_CV1
Ethernet and USB 2.0 connectors RJ-45, USB 2.0 LAN2_USB_01_2
Ethernet and USB 3.0 connectors RJ-45, USB 3.0 LAN1_USB3_1
Keyboard and mouse connectors Dual PS/2 KBMS1
Serial port and VGA connector DB-9 male,
DB-15 female
VGACOM1
USB 2.0 connectors USB 2.0 LAN2_USB_01_1
Table 3-2: Rear Panel Connectors
