IMBA-C604EP ATX Server Board

Page 8

Specification/Model

IMBA-C604EP

Fan Connectors

One 4-pin CPU fan connector

Five 4-pin system fan connectors

Front Panel

One 24-pin header (power LED, HDD LED, LAN LED, speaker, power

button, reset button)

I2C

One 4-pin wafer connector

Keyboard/Mouse

Dual PS/2 port

PSMI (PMBus)

One 5-pin box header

Serial ATA

Two SATA 6Gb/s connectors (RAID 0, 1, 10, 5 support)

Four SATA 3Gb/s connectors (RAID 0, 1, 10, 5 support)

Serial Attached SCSI

Four SAS 3Gb/s connectors (RAID 0, 1, 10 support)

Serial Ports

One external RS-232 serial port

SMBus

One 4-pin wafer connector

TPM

One via 20-pin header

USB Ports

Two external USB 3.0 ports on rear IO

Four external USB 2.0 ports on rear IO

Six internal USB 2.0 ports by three pin headers

One internal USB 2.0 port by Type A

Environmental and Power Specifications

Power Supply

AT/ATX power supply

Power Consumption

[email protected] (2.1 GHz Intel® Xeon® E5-2658 CPU with four 4 GB

1333 MHz DDR3 memory)

Operating

Temperature

-10ºC ~ 60ºC

Storage

Temperature

-20ºC ~ 70ºC

Humidity

5% ~ 95% (non-condensing)
