5.3.12 Main Configuration Page
The Main Configuration Page menus (BIOS Menu 16) configure the LAN ports and
display the configuration information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PORT CONFIGURATION MENU
> NIC Configuration
Blink LEDs (range 0-15 seconds) 0
PORT CONFIGURATION INFORMATION
UEFI Driver:
Intel(R) PRO/1000 5.3
Adapter PBA: FFFFFF-0FF
Chip Type: Intel 82574
PCI Device ID 10D3
PCI Bus:Device:Function: 8:0:0
Link Status [Disconnected]
Factory MAC Address: 00:00:0F:12:34:98
Click to configure the
network device port.
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Main Configuration Page
Î Blink LEDs (range 0-15 seconds)
This option allows to specify the duration to blink the LAN LEDs. Manually enter the value
ranging from 0 to 15 seconds.
Î PORT CONFIGURATION INFORMATION
Displays the LAN port configuration information.
