IMBA-C604EP ATX Server Board
Page 16
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
+12V power source connector 8-pin Molex CPU12V1
ATX power connector 24-pin ATX ATX1
Battery holder CR2032 battery holder BAT1
Chassis intrusion connector 2-pin header JCHASSIS1
DDR3 DIMM slots DDR3 DIMM slot
DIMMA1, DIMMA2,
DIMMB1, DIMMB2,
DIMMC1, DIMMC2,
DIMMD1, DIMMD2
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connectors (system) 4-pin wafer
SYS_FAN1,
SYS_FAN2,
SYS_FAN3,
SYS_FAN4,
SYS_FAN5
Front panel audio connector 10-pin header FP_AUDIO1
Front panel connector 24-pin header SSI_F_PANEL1
I2C connector 4-pin wafer I2C_1
PCIe x8 slots PCIe x8 slot
PCIEX8_SLOT1,
PCIEX8_SLOT2,
PCIEX8_SLOT3,
PCIEX8_SLOT4,
PMBus connector 5-pin box header PMBUS1
SAS 3Gb/s drive connector 7-pin SAS connector
SAS1, SAS2
SAS3, SAS4
SAS LED connector 4-pin wafer SAS_LED1
