 L2 Cache: Lists the amount of storage space on the L2 cache.

 L3 Cache: Lists the amount of storage space on the L3 cache.

5.3.4 S ATA Co n fig u ra tio n

Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the

configuration of the SATA devices installed in the system.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Advanced

SATA Configuration


SATA Mode

[IDE Mode]

Serial-ATA Controller 0

[Compatible]

Serial-ATA Controller 1

[Enhanced]

SATA Port0

Not Present


SATA Port1

Not Present


SATA Port2

Not Present


SATA Port3

Not Present


(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.

---------------------
: Select Screen
↑ ↓: Select Item
Enter

Select

+/-: Change Opt.
F1

General Help

F2

Previous Values

F3

Optimized Defaults

F4

Save & Exit

ESC Exit

Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 7: IDE

Configuration

 S ATA Mo d e [IDE Mo d e ]

Use the SATA Mode option to configure SATA devices as normal IDE devices.

Disable

Disables SATA devices.

IDE Mode

D

EFAULT

Configures SATA devices as normal IDE device.

ACHI Mode

Configures SATA devices as AHCI device.

RAID Mode

Configures SATA devices as RAID device.

 Serial-ATA Co n tro ller 0 [Co m patib le ]

Use the Serial-ATA Controller 0 option to configure the Serial-ATA controller mode when

the SATA mode is set to IDE Mode.
