CN P in o u ts :

See Table 3-4

The battery connector is connected to the system battery. The battery provides power to

the system clock to retain the time when power is turned off.

Figure 3-3: Battery Connector Location

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1

VBATT

2

GND

Table 3-4: Battery Connector Pinouts

3.2.3 CP U P o we r Co n n e c to r

CN La b e l:

CP U12V1

CN Typ e :

4-pin Molex

CN Lo c a tio n :

See Figure 3-4

CN P in o u ts :

See Table 3-5

The CPU power connector provides power to the CPU.
