KINO-AQ670
P a g e 34
The USB 3.0 ports are for attaching USB 3.0 peripheral devices to the system. To be able
to use the USB 3.0 ports, please make sure the USB 3.0 function is enabled in BIOS (see
Section 5.3.6). The pinouts of LAN2 and USB 3.0 connectors are shown below.
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 USB3_PWR1 2 USB2P0_DM1
3 USB2P0_DP1 4 GND
5 USB3P0_RXDN1 6 USB3P0_RXDP1
7 GND 8 USB3P0_TXDN1
9 USB3P0_TXDP1 10 USB3_PWR2
11 USB2P0_DM2 12 USB2P0_DP2
13 GND 14 USB3P0_RXDN2
15 USB3P0_RXDP2 16 GND
17 USB3P0_TXDN2 18 USB3P0_TXDP2
19 +1.05V_LAN2 20 TRD2P0
21 TRD2N0 22 TRD2P1
23 TRD2N1 24 TRD2P2
25 TRD2N2 26 TRD2P3
27 TRD2N3 28 GND
29 +3.3V_LAN 30 L2_LINK_ACT#
31 L2_100# 32 L2_1000#
Table 3-16: LAN2_USB Connector Pinouts
3.3.3 Ke yb o a rd /Mo u s e Co n n e c to r
CN La b e l: KB_MS
CN Typ e : Dual PS/2
CN Lo c a tio n : See Figure 3-18
CN P in o u ts : See Table 3-17
The PS/2 ports are for connecting a PS/2 mouse and a PS/2 keyboard.
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
