KINO-AQ670
P a g e 49
If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault
may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the
following:
  Enter the correct CMOS setting
  Load Optimal Defaults
  Load Failsafe Defaults.
After having done one of the above, save the changes and exit the CMOS Setup menu.
The clear CMOS jumper settings are shown in Table 4-3.
Setting Description
Short 1-2 Normal Operation Default
Short 2-3 Clear CMOS Setup
Table 4-3: Clear CMOS Jumper Settings
The location of the clear CMOS jumper is shown in Figure 4-10.
Figure 4-10: Clear CMOS Jumper Location
4.4.3 WOL Mo d e S e le c t J u m p e r
J u m p e r La b e l: WOL_SEL1
