KINO-AQ670
P a g e 14
3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
ATX power connector 24-pin ATX ATX
Battery connector 2-pin wafer BAT2
CPU power connector 4-pin Molex CPU12V1
DDR3 SO-DIMM slots DDR3 SO-DIMM slot
CHA_DIMM1,
CHB_DIMM1
Debug port connector 9-pin header DEBUGCN1
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN
Fan connector (PCH) 4-pin wafer PCH_FAN
Front Panel connector 14-pin header F_PANEL
PCIe x16 slot PCIe x16 slot PCIEX16
SATA 3Gb/s drive connectors 7-pin SATA connector SATA3, SATA4
SATA 6Gb/s drive connectors 7-pin SATA connector SATA1, SATA2
SMBus connector 4-pin wafer SMBUS_1
SPI connector 8-pin header SPI
TPM connector 20-pin connector TPM
USB connectors 8-pin header USB1, USB4
Table 3-1: Peripheral Interface Connectors
3.1.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below lists the connectors on the external I/O panel.
