78
CATC M ERLIN ’ S W AND 2.00 C HAPTER 8
User’s Manual Using Merlin to Record Merlin’s Wand Traffic
8.2 Set Up Connection Options
In addition to establishing connections, the Connect/Disconnect Merlin
Bluetooth Analyzer button
provides several options for configuring
the connection between Merlin's Wand and Merlin. To see the options, click
on the options arrow on the right side of the button.
Run Merlin on a Local Machine
To run Merlin on a local machine, click the
options arrow on the right side of the
Connect/Disconnect Merlin button and make
sure that “Run on local” is selected in the
Connect/Disconnect options menu. When
selected, a checkmark appears next to it.
Add a Remote Machine
Merlin's Wand can be configured to control a Merlin analyzer that is running
on a remote computer. Before Merlin's Wand can connect to Merlin, the
remote machine that runs Merlin must be added to the Connect/Disconnect
options menu in Merlin's Wand.
Step 1
Click the options arrow on the right side of the
Connect/Disconnect Merlin button and select “Add remote
machine...” from the options menu.
The Remote Machine dialog will open.
Step 2 Enter the Internet machine name or IP address for the
machine on which Merlin is running and click OK.
Note : If the machine name is used and Merlin's Wand
is subsequently unable to connect to Merlin,
then the IP address must be used instead.
