14
CATC M ERLIN ’ S W AND 2.00 C HAPTER 2
User’s Manual Getting Started
Tools and Modes
Merlin/Merlin Mobile Analyzer Toolbar
2.8 Tool Tips
For most of the buttons and menus, tool tips provide
useful information.
To display a tool tip, position the mouse pointer over an
item. If a tooltip exists for the item, it will pop up in a
moment.
Device Search
Opens Device Search dialog
Local Device Manager
Displays info about Merlin’s Wand
Profile Wizard
Opens Profile Wizard
Command Generator
Opens Command Generator
Script Manager
Opens Script Manager
Data Transfer Manager
Opens Data Transfer Manager dialog
Connect/Disconnect Merlin Bluetooth Analyzer
Connects to or disconnects from Merlin Bluetooth Analyzer
Set Merlin Recording Options
Displays the Open dialog to choose the Recording Options file
for Merlin Bluetooth Analyzer
Set Merlin Display Options
Displays the Open dialog to choose the Display Options file
for Merlin Bluetooth Analyzer
Start Recording
Starts a Merlin Bluetooth Analyzer recording session
Stop Recording
Stops a Merlin Bluetooth Analyzer recording session
Set Merlin Encryption Options
Opens the Encryption Setup window
