Teledyne LeCroy Merlins Wand - Users Manual - Manual (Page 170)

154
CATC M ERLIN ’ S W AND 2.00 C HAPTER B
User’s Manual Command Generator Examples
Step 4
Click Execute.
The Event Log should indicate that a connection was established.
Step 5 Select ClientGet from the command menu.
Step 6
Type in the name of a file that is to be transferred from the
Server into the Object parameter box.
Step 7 Click Execute.
The Event Log should indicate that the file was transferred. A Save As
dialog box should open.
Step 8
Enter a name for the file you are retrieving. Select a directory, then
click Save.
Step 9
Select ClientPut from the command menu.
Step 10 In the box marked Filename, type the name of a file that is to be
transferred to the server, or use the browse
button to locate the
file you want to put. The Open dialog will come up, allowing you to
navigate to the desired file.
Step 11
Click Execute.
The Event Log should indicate that the file was transferred.
