Chapter 4
Appendix
68
IA Net
XSEL-R/S
Error
Code
Error Name Check Items Check/Treatment
548
IA Net Resizing
Overlapping Error
Aren’t there several stations to execute
resizing?
Check that the value set in I/O Parameter
No.603 “IA Net Resizing Executed Station
No.” matches to the controller in the same
network.
Check if the station number is exceeding
63.
Check the values in I/O Parameters No.601
“IA Net Occupied Station No.”, No.602 “IA Net
Top Occupied Station Number” and No.604
“IA Net Final Station Number”.
Check if the station number of the
controller itself is exceeding the final
station number.
Confirm that the value set in I/O Parameter
No.602 “IA Net Occupied Station Top No.” is
smaller than what is set in I/O Parameter
No.604 “IA Net Final Station No.”.
Isn’t the resizing executed station
number exceeding the final station
number?
Confirm that the value set in I/O Parameter
No.603 “IA Net Resizing Executed Station
No.” is smaller than what is set in I/O
Parameter No.604 “IA Net Final Station No.”.
Check if the controller itself is being
subject to the resizing executed station.
Confirm that the value set in I/O Parameter
No.603 “IA Net Resizing Executed Station
No.” is the same as what is set in No.602 “IA
Net Occupied Station Top No.”.
Is the controller itself involved in the all
connected stations pattern parameter?
Check if all the stations in the controller are
set in I/O Parameters No.605 and 606 “IA Net
All Connected Station Patterns
(31-00)/(63-32)”.
54C
IA Net Communication
Parameter Error
Isn’t the all connected stations parameter
including a station number later than the
final station number?
Check if no station number later than what is
set in I/O Parameter No.604 “IA Net Final
Station Number” is set in I/O Parameters
No.605 and 606 “IA Net All Connected Station
Patterns (31-00)/(63-32)”.
560
IA Net Number of
Occupied Stations
Overflow Error
Check if the total of the occupied number
determined by the number of the I/O
communication use Output points and
occupied number determined by the
number of the extension I/O unit DO use
exceeds four stations.
Confirm the number of occupied stations from
I/O Parameter No.701 “IA Net Shared
Number of Outputs Use” and No.705
“Extension I/O Unit Use Select”.
561
IA Net I/O Assignment
Number Overflow Error
Isn’t the number of the shared word to
acquire from exceeding 16?
Make sure that the total number of ON bits in
I/O Parameters No.693 to 700 “IA Net
Common Input Acquisition Shared Word
Patterns” is not exceeding 16 bits.
Check if the station numbers for X-SEL
and the extension I/O unit are duplicated.
Check the values in I/O Parameters No.602
“IA Net Occupied Station Top No.” and No.706
“Extension I/O Unit No.”.
Check if trying to use an extension I/O
unit with a greater station number than
what it is for I/O Parameter No.604 “IA
Net Final Station Number”.
Check the values in I/O Parameters No.604
“IA Net Final Station No.” and No.706
“Extension I/O Unit No.”.
562
Extension I/O Unit
Parameter Error
Isn’t an extension I/O unit being subject
to resizing executed station?
Check the values in I/O Parameters No.603
“IA Net Resizing Executed Station No.” and
No.706 “Extension I/O Unit No.”.
563
Extension I/O Unit DO
Duplication Error
Aren’t another X-SEL controller and an
extension I/O unit used DO competing
with each other?
DO cannot be used for multiple XSEL at the
same time. Revise the setting in I/O
Parameter No.705 “Extension I/O Unit Use
Select”.
Check the extension I/O unit is
connected to IA Net.
Check the conditions of 24V power supply for
extension I/O units, IA Net cables and the
mount of the terminal resistors.
564
Extension I/O Unit Initial
Communication Timeout
Error
Is the extension I/O unit set in the
parameter matching with the station
number actually connected?
Make sure the number set in I/O Parameter
No.706 “Extension I/O Unit No.” is matching
with the condition of the unit number setting
switch on the extension I/O unit.
565
Extension I/O Unit
Board Undetected Error
Is the I/O slot that you are trying to use
equipped with DIO boards?
Confirm that an I/O slot with no DIO board
mounted on is not set to be used in the setting
of I/O Parameter No.705 “Extension I/O Unit
Use Select”.
567
IA Net Communication
Cycle Time Error
Check that the same final station number
as the resizing executed station is set to
the final station number.
Confirm that the setting in I/O Parameter
No.604 “IA Net Final Station No.” is the same
in all the controllers.
